IFM DTE101 RFID Evaluation Unit LF/HF
- Brand
- IFM
- Model
- DTE101
- GEARWELL SKU
- GWP-000002297
- Category
- Industrial Automation Parts
Key specifications
- Weight
- 393.5 g
- Dimensions
- 115 x 85 x 46.2 mm
- Protection
- IP 67
- Product type
- RFID evaluation unit LF/HF
- Operating voltage
- 18...30 V DC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm DTE101 (DTELF/HFABRWPNUS00) is an RFID evaluation unit for up to four LF or HF read/write heads (ANT4xx, ANT5xx, ANT600) with a PROFINET interface. It has four digital outputs rated at 500 mA (IO 1, 2) or 1000 mA (IO 3, 4), runs on 18…30 V DC, connects to Ethernet through two D-coded M12 connectors and mounts on a DIN rail. The 115 x 85 x 46.2 mm housing has an orange PA upper part and a die-cast aluminum lower part and is rated IP67 for -20…60 °C ambient. An M12 protective cap (E73004) is supplied.
Technical reference
| Product name | IFM DTE101 RFID Evaluation Unit LF/HF |
|---|---|
| Brand | IFM |
| Model | DTE101 |
| Category | Industrial Automation Parts |
| Weight | 393.5 g |
| Dimensions | 115 x 85 x 46.2 mm |
| Protection | IP 67 |
| Product type | RFID evaluation unit LF/HF |
| Operating voltage | 18...30 V DC |
| Ambient temperature | -20...60 °C |
| Current consumption | < 3000 mA |
| Communication interface | Ethernet |
