IFM DN1030 PSU-1AC/24VDC-1,3A Switched-mode Power Supply 24 V DC
- Brand
- IFM
- Model
- DN1030
- GEARWELL SKU
- GWP-000008378
- Category
- Power Supplies
Key specifications
- Weight
- 278.5 g
- Housing
- rectangular
- Materials
- housing: PC/ABS
- Dimensions
- 90 x 45 x 100 mm
- Protection
- IP 20
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm DN1030 (PSU-1AC/24VDC-1,3A) is a switched-mode power supply for DIN rail mounting with an input range of 100…240 V AC (47…63 Hz) and an adjustable output of 24…28 V DC. It delivers up to 1.25 A, with residual ripple below 50 mV, 84 % efficiency and 120 ms mains buffering at 230 V AC; the output is short-circuit proof and SELV/PELV. The PC/ABS housing measures 90 x 45 x 100 mm, needs 30 mm free space for convection cooling and is rated IP20 for 0…70 °C ambient; above 60 °C the output is derated by 2 % per K.
Technical reference
| Product name | IFM DN1030 PSU-1AC/24VDC-1,3A Switched-mode Power Supply 24 V DC |
|---|---|
| Brand | IFM |
| Model | DN1030 |
| Category | Power Supplies |
| Weight | 278.5 g |
| Housing | rectangular |
| Materials | housing: PC/ABS |
| Dimensions | 90 x 45 x 100 mm |
| Protection | IP 20 |
| Ambient temperature | 0...70 °C |
