IFM DTA200 RFID Read/Write Antenna with AS-Interface
- Brand
- IFM
- Model
- DTA200
- GEARWELL SKU
- GWP-000000039
- Category
- Industrial Automation Parts
Key specifications
- Protection
- IP 67; IP 69K
- Product type
- RFID read/write antenna with AS-Interface
- Travel speed
- < 0.5 m/s
- Electrical design
- AS-i
- Operating voltage
- 26.5...31.6 V DC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm DTA200 (DTSLF MCRWASUS01) is an LF RFID read/write antenna working at 125 kHz with an AS-Interface connection (ID code 4, certificate 87201), for detecting objects on transport equipment at travel speeds below 0.5 m/s. ifm gives a static read distance of up to 55 mm and a minimum spacing between heads of 300 mm front and side. It runs on 26.5…31.6 V DC from AS-i, has a 40 x 40 x 54 mm PA housing with a sensing face that can be set to 5 positions, connects through an M12 connector (A-coded, 4 contacts) and is rated IP67 and IP69K for -20…60 °C ambient.
Technical reference
| Product name | IFM DTA200 RFID Read/Write Antenna with AS-Interface |
|---|---|
| Brand | IFM |
| Model | DTA200 |
| Category | Industrial Automation Parts |
| Protection | IP 67; IP 69K |
| Product type | RFID read/write antenna with AS-Interface |
| Travel speed | < 0.5 m/s |
| Electrical design | AS-i |
| Operating voltage | 26.5...31.6 V DC |
| Current consumption | < 75 mA |
| Operating frequency | 0,125 MHz |
| Communication interface | AS-i |
