IFM DP3213 CONV IO-LINK/2x4-20mA/IP69K Converter IO-Link - 4...20 mA
- Brand
- IFM
- Model
- DP3213
- GEARWELL SKU
- GWP-000008647
- Category
- Industrial Communication
Key specifications
- Housing
- rectangular
- Dimensions
- 63 x 30 x 24.5 mm
- Protection
- IP 67; IP 69K
- Operating voltage
- 18...30 DC ((in wet environments: 18...28 V) to SELV/PELV) V
- Ambient temperature
- -25...70 °C
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm DP3213 (CONV IO-LINK/2x4-20mA/IP69K) is a converter that provides two 4…20 mA analog outputs controlled over IO-Link (revision 1.1), for connecting analog actuators to an IO-Link system, including in wet environments. ifm gives an output precision of 0.25 % and a maximum load of 300 Ω; it runs on 18…30 V DC (18…28 V in wet environments). The PA housing measures 63 x 30 x 24.5 mm with a stainless steel nut and FKM seal, connects through an M12 connector (A-coded, 4 contacts) and is rated IP67 and IP69K for -25…70 °C ambient. It has UL approval under file E205959.
Technical reference
| Product name | IFM DP3213 CONV IO-LINK/2x4-20mA/IP69K Converter IO-Link - 4...20 mA |
|---|---|
| Brand | IFM |
| Model | DP3213 |
| Category | Industrial Communication |
| Housing | rectangular |
| Dimensions | 63 x 30 x 24.5 mm |
| Protection | IP 67; IP 69K |
| Operating voltage | 18...30 DC ((in wet environments: 18...28 V) to SELV/PELV) V |
| Ambient temperature | -25...70 °C |
| Current consumption | 300 mA |
| Communication interface | IO-Link |
| Number of analogue outputs | 2 |
