IFM DI0101 Compact evaluation unit for speed monitoring
- Brand
- IFM
- Model
- DI0101
- GEARWELL SKU
- GWP-000012253
- Category
- Relays & Controllers
Key specifications
- Housing
- Threaded type
- Dimensions
- M30 x 1.5 / L = 80 mm
- Application
- simple evaluation of rotating and linear movement with regard to underspeed; blocking
- Sensing range
- 10 mm
- Setting range
- 5...3600 Imp/min
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm DI0101 (DIA2010-ZROA/5-3600 I/MIN) is a compact inductive evaluation unit for underspeed and blocking of rotating and linear movements, in an M30 x 1.5 housing 80 mm long for flush mounting. It senses targets at up to 10 mm (real sensing range 10 mm ± 10%), and its switch point is set with a multiturn potentiometer over 5…3600 pulses/min, with a start-up delay of 12 s. The normally open output is rated at 350 mA on AC and 100 mA on DC; it runs on 20…250 V AC/DC, connects through a 2 m PUR cable with 2 x 0.5 mm² conductors and is rated IP65 and IP67 for -25…80 °C ambient. Two lock nuts are supplied.
Technical reference
| Product name | IFM DI0101 Compact evaluation unit for speed monitoring |
|---|---|
| Brand | IFM |
| Model | DI0101 |
| Category | Relays & Controllers |
| Housing | Threaded type |
| Dimensions | M30 x 1.5 / L = 80 mm |
| Application | simple evaluation of rotating and linear movement with regard to underspeed; blocking |
| Sensing range | 10 mm |
| Setting range | 5...3600 Imp/min |
| Nominal voltage AC | 20...250 V |
| Nominal voltage DC | 20...250 V |
