IFM PA3589 Pressure Transmitter

Product overview

The ifm PA3589 (PA-,10BRBG14-A-ZVG/US/ /V) is a pressure transmitter with ceramic measuring cell for liquids and gases. It measures relative pressure over 0…0.1 bar (0…100 mbar), with a pressure rating of 4000 mbar and a minimum burst pressure of 30000 mbar. The process connection is a G 1/4 external thread (DIN EN ISO 1179-2) with M5 internal thread, the wetted parts are stainless steel (1.4305 / 303), ceramics and FKM seal, and the permitted medium temperature is -25…90 °C. It provides 1 analog output (4…20 mA), runs on 9.6…32 V DC and connects through an M12 connector (A-coded, 2 gold-plated contacts). ifm specifies characteristic deviation < ± 0.5 % of span and repeatability < 0.2 % of span. The sensor is rated IP68 for -25…80 °C ambient.
