IFM PA3029 Pressure Transmitter with Ceramic Measuring Cell

Product overview

The ifm PA3029 (PA-0-1-RBR14-A-ZVG/US/ /V) is a pressure transmitter with ceramic measuring cell for liquids and gases. It measures relative pressure and vacuum over -1…0 bar (-1000…0 mbar), with a pressure rating of 10 bar and a minimum burst pressure of 30 bar. The process connection is a G 1/4 internal thread, the wetted parts are stainless steel (1.4305 / 303), ceramics and FKM, and the permitted medium temperature is -25…90 °C. It provides 1 analog output (4…20 mA), runs on 9.6…32 V DC and connects through an M12 connector (A-coded, 4 gold-plated contacts). ifm specifies characteristic deviation < ± 0.25 % of span and repeatability < 0.1 % of span. The sensor is rated IP65 for -25…80 °C ambient.
