IFM PE2096 Industrial Sensor
- Brand
- IFM
- Model
- PE2096
- GEARWELL SKU
- GWP-000000124
- Category
- Industrial Automation Parts
Key specifications
- Output signal
- Switching signal; analogue signal; IO-Link (configurable)
- Response time
- < 1.5 ms
- Measuring range
- -0.125...2.5 bar
- Electrical design
- PNP/NPN
- Switching frequency DC
- < 500 Hz
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm PE2096 (PE-2,5-RER14-MFRKG/US/ /E) is a pressure sensor with display for liquids and gases. It measures relative pressure over -0.125…2.5 bar (-125…2500 mbar), with a pressure rating of 20 bar and a minimum burst pressure of 50 bar. The process connection is a G 1/4 internal thread, the wetted parts are stainless steel (1.4404 / 316L), ceramics (99.9 % Al2O3) and EPDM, and the permitted medium temperature is -25…80 °C. It provides 2 switching outputs (PNP/NPN), 1 analog output (4…20 mA or 0…10 V) and IO-Link, runs on 18…30 V DC and connects through an M12 connector (A-coded, 4 gold-plated contacts). ifm specifies characteristic deviation < ± 0.25 % of span and repeatability < ± 0.1 % of span. The sensor is rated IP65 and IP67 for -25…80 °C ambient.
Technical reference
| Product name | IFM PE2096 Industrial Sensor |
|---|---|
| Brand | IFM |
| Model | PE2096 |
| Category | Industrial Automation Parts |
| Output signal | Switching signal; analogue signal; IO-Link (configurable) |
| Response time | < 1.5 ms |
| Measuring range | -0.125...2.5 bar |
| Electrical design | PNP/NPN |
| Switching frequency DC | < 500 Hz |
| Analogue current output | 4...20 mA (scalable 1:5) |
| Analogue voltage output | 0...10 V (scalable 1:5) |
| Number of inputs and outputs | Digital outputs: 2; analogue outputs: 1 |
