IFM PA9020 PA pressure transmitters Pressure transmitter with ceramic measuring cell
- Brand
- IFM
- Model
- PA9020
- GEARWELL SKU
- GWP-000030034
- Category
- Pressure, Flow & Temperature
Key specifications
- Media
- liquids and gases
- Output signal
- analog signal
- Measuring range
- 0...400 bar / 0...5800 psi / 0...40 MPa
- Pressure rating
- 600 bar / 8700 psi / 60 MPa
- Operating voltage
- 16...32 DC V
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | IFM PA9020 PA pressure transmitters Pressure transmitter with ceramic measuring cell |
|---|---|
| Brand | IFM |
| Model | PA9020 |
| Category | Pressure, Flow & Temperature |
| Media | liquids and gases |
| Output signal | analog signal |
| Measuring range | 0...400 bar / 0...5800 psi / 0...40 MPa |
| Pressure rating | 600 bar / 8700 psi / 60 MPa |
| Operating voltage | 16...32 DC V |
| Medium temperature | -25...90; (on request: -40...90 °C) °C |
| Process connection | threaded connection G 1/4 Internal thread |
| Analog voltage output | 0...10 V |
