GE IC693MDL741 Series 90-30 12/24 VDC Negative Logic Output Module
- Brand
- GE
- Model
- IC693MDL741
- GEARWELL SKU
- GWP-000025757
- Category
- PLCs & I/O
Key specifications
- Outputs
- 16, two groups of eight, negative logic (sinking)
- Evidence
- GE Fanuc GFK-0898F Series 90-30 PLC I/O Module Specifications page (hosted at qualitrol.com)
- Isolation
- 1500 V field to logic, 500 V between groups
- Rated voltage
- 12/24 VDC (12 to 24 VDC +20 %/-15 %)
- Response time
- 2 ms maximum on/off
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC693MDL741 Series 90-30 12/24 VDC Negative Logic Output Module |
|---|---|
| Brand | GE |
| Model | IC693MDL741 |
| Category | PLCs & I/O |
| Outputs | 16, two groups of eight, negative logic (sinking) |
| Evidence | GE Fanuc GFK-0898F Series 90-30 PLC I/O Module Specifications page (hosted at qualitrol.com) |
| Isolation | 1500 V field to logic, 500 V between groups |
| Rated voltage | 12/24 VDC (12 to 24 VDC +20 %/-15 %) |
| Response time | 2 ms maximum on/off |
| Catalog number | IC693MDL741 |
| Output current | 0.5 A per point, 2 A per common |
| Power consumption | 110 mA from 5 V backplane bus (all outputs on) |
| Output voltage drop | 0.5 V maximum |
