GE IC693MDL655 Series 90-30 24 VDC Pos/Neg Logic Input Module 32 Point
- Brand
- GE
- Model
- IC693MDL655
- GEARWELL SKU
- GWP-000026592
- Category
- PLCs & I/O
Key specifications
- Evidence
- GE Fanuc GFK-0898F Series 90-30 PLC I/O Module Specifications, IC693MDL655 pages (hosted at qualitrol.com)
- Isolation
- 1500 V field to logic; 250 V between groups
- Connectors
- two 24-pin male connectors (Fujitsu FCN-365P024-AU)
- Input current
- 7.0 mA typical at 24 VDC
- Rated voltage
- 24 VDC, positive or negative logic
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC693MDL655 Series 90-30 24 VDC Pos/Neg Logic Input Module 32 Point |
|---|---|
| Brand | GE |
| Model | IC693MDL655 |
| Category | PLCs & I/O |
| Evidence | GE Fanuc GFK-0898F Series 90-30 PLC I/O Module Specifications, IC693MDL655 pages (hosted at qualitrol.com) |
| Isolation | 1500 V field to logic; 250 V between groups |
| Connectors | two 24-pin male connectors (Fujitsu FCN-365P024-AU) |
| Input current | 7.0 mA typical at 24 VDC |
| Rated voltage | 24 VDC, positive or negative logic |
| Response time | 2 ms maximum on / off |
| Catalog number | IC693MDL655 |
| Inputs per module | 32 (four groups of eight) |
| Power consumption | 195 mA max from +5 V bus; 224 mA typical from isolated +24 V bus or user supply |
| Input voltage range | 0 to 30 VDC |
