GE IC693MDL742 Series 90-30 12/24 VDC 16-Point ESCP Output Module
- Brand
- GE
- Model
- IC693MDL742
- GEARWELL SKU
- GWP-000034312
- Category
- PLCs & I/O
Key specifications
- Outputs
- 16 (two groups of 8), positive logic
- Evidence
- GE Fanuc GFK-0898F Series 90-30 PLC I/O Module Specifications page (maker document hosted at qualitrol.com)
- Isolation
- 1500 V field to logic; 500 V between groups
- Protection
- electronic short circuit protection per group
- Rated voltage
- 12/24 VDC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC693MDL742 Series 90-30 12/24 VDC 16-Point ESCP Output Module |
|---|---|
| Brand | GE |
| Model | IC693MDL742 |
| Category | PLCs & I/O |
| Outputs | 16 (two groups of 8), positive logic |
| Evidence | GE Fanuc GFK-0898F Series 90-30 PLC I/O Module Specifications page (maker document hosted at qualitrol.com) |
| Isolation | 1500 V field to logic; 500 V between groups |
| Protection | electronic short circuit protection per group |
| Rated voltage | 12/24 VDC |
| Catalog number | IC693MDL742 |
| Output current | 1 A per point; 4 A per group at 50 °C |
| Backplane power | 130 mA from 5 V bus (all outputs on) |
| Output voltage range | 12 to 24 VDC (+20%, -15%) |
