GE IC693MDL753 Series 90-30 12/24 VDC 0.5A Output Module 32 Point
- Brand
- GE
- Model
- IC693MDL753
- GEARWELL SKU
- GWP-000026593
- Category
- PLCs & I/O
Key specifications
- Evidence
- GE Fanuc GFK-0898F Series 90-30 PLC I/O Module Specifications, IC693MDL753 pages (hosted at qualitrol.com)
- Isolation
- 1500 V field to logic; 250 V between groups
- Connectors
- two 24-pin male connectors (Fujitsu FCN-365P024-AU)
- Rated voltage
- 12 through 24 VDC, positive logic
- Response time
- 0.5 ms maximum on / off
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC693MDL753 Series 90-30 12/24 VDC 0.5A Output Module 32 Point |
|---|---|
| Brand | GE |
| Model | IC693MDL753 |
| Category | PLCs & I/O |
| Evidence | GE Fanuc GFK-0898F Series 90-30 PLC I/O Module Specifications, IC693MDL753 pages (hosted at qualitrol.com) |
| Isolation | 1500 V field to logic; 250 V between groups |
| Connectors | two 24-pin male connectors (Fujitsu FCN-365P024-AU) |
| Rated voltage | 12 through 24 VDC, positive logic |
| Response time | 0.5 ms maximum on / off |
| Catalog number | IC693MDL753 |
| Output current | 0.5 A per point, 4 A maximum per group |
| Power consumption | 260 mA max from 5 V backplane bus |
| Outputs per module | 32 (four groups of eight) |
| Output voltage range | 10.2 to 28.8 VDC |
