GE IC693MDL752 Series 90-30 5/24 VDC TTL 32-Point Output Module
- Brand
- GE
- Model
- IC693MDL752
- GEARWELL SKU
- GWP-000034313
- Category
- PLCs & I/O
Key specifications
- Outputs
- 32 (four groups of 8)
- Evidence
- GE Fanuc GFK-0898F Series 90-30 PLC I/O Module Specifications page (maker document hosted at qualitrol.com)
- Isolation
- 1500 V field to logic; 250 V between groups
- Rated voltage
- 5 and 12 to 24 VDC, negative logic
- Response time
- 0.5 ms max on/off
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC693MDL752 Series 90-30 5/24 VDC TTL 32-Point Output Module |
|---|---|
| Brand | GE |
| Model | IC693MDL752 |
| Category | PLCs & I/O |
| Outputs | 32 (four groups of 8) |
| Evidence | GE Fanuc GFK-0898F Series 90-30 PLC I/O Module Specifications page (maker document hosted at qualitrol.com) |
| Isolation | 1500 V field to logic; 250 V between groups |
| Rated voltage | 5 and 12 to 24 VDC, negative logic |
| Response time | 0.5 ms max on/off |
| Catalog number | IC693MDL752 |
| Output current | 25 mA/point TTL; 0.5 A/point 12/24V; 4 A per group |
| Output voltage range | 4.75-5.25 VDC (TTL); 10.2-28.8 VDC (12/24V) |
