EUCHNER TP3-4141A024MC1844 TP Safety Switch with Guard Locking
- Brand
- EUCHNER
- Model
- TP3-4141A024MC1844
- GEARWELL SKU
- GWP-000001972
- Category
- Industrial Automation Parts
Key specifications
- Protection rating
- IP67
- Product type
- TP safety switch with guard locking
- Locking force
- 1300 N maximum; 1000 N Fzh
- Solenoid operating voltage
- 24 V AC/DC, -15% to +10%
- Power consumption
- 8 W
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The EUCHNER TP3-4141A024MC1844 is a TP series electromechanical safety switch with guard locking in version C1844, whose auxiliary release is fitted with an identical-locking lock. Guard locking follows the closed-circuit current principle: spring force keeps the guard locked until the 24 V AC/DC solenoid is energized (power to unlock), with locking forces of 1300 N (F max) and 1000 N (F Zh). Slow-action switching element 4141 provides 2 positively driven contacts for guard lock monitoring and 2 positively driven contacts for the door position, rated AC-15 4 A 230 V and DC-13 4 A 24 V. The reinforced thermoplastic housing has 3 cable entries M20 x 1.5, IP67 protection and an ambient range of -20 to 55 °C; the actuator is ordered separately.
Technical reference
| Product name | EUCHNER TP3-4141A024MC1844 TP Safety Switch with Guard Locking |
|---|---|
| Brand | EUCHNER |
| Model | TP3-4141A024MC1844 |
| Category | Industrial Automation Parts |
| Protection rating | IP67 |
| Product type | TP safety switch with guard locking |
| Locking force | 1300 N maximum; 1000 N Fzh |
| Solenoid operating voltage | 24 V AC/DC, -15% to +10% |
| Power consumption | 8 W |
| Ambient temperature | -20 to 55 °C |
| Contact configuration | 2 guard-lock NC + 2 door-monitoring NC contacts |
| Guard locking principle | Closed-circuit current; power to unlock |
