EUCHNER TP3-2131A024MC2183 TP Safety Switch with Guard Locking
- Brand
- EUCHNER
- Model
- TP3-2131A024MC2183
- GEARWELL SKU
- GWP-000003425
- Category
- Industrial Automation Parts
Key specifications
- Protection rating
- IP67
- Product type
- TP safety switch with guard locking
- Locking force
- 1300 N maximum; 1000 N Fzh
- Solenoid operating voltage
- 24 V AC/DC
- Power consumption
- 8 W
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | EUCHNER TP3-2131A024MC2183 TP Safety Switch with Guard Locking |
|---|---|
| Brand | EUCHNER |
| Model | TP3-2131A024MC2183 |
| Category | Industrial Automation Parts |
| Protection rating | IP67 |
| Product type | TP safety switch with guard locking |
| Locking force | 1300 N maximum; 1000 N Fzh |
| Solenoid operating voltage | 24 V AC/DC |
| Power consumption | 8 W |
| Ambient temperature | -20 to 55 °C |
| Contact configuration | 2 guard-lock NC + 1 guard-lock NO + 1 door-position NC |
| Guard locking principle | Closed-circuit current; power to unlock |
