EUCHNER TP4-4141A024M Industrial Sensor

Product overview

The EUCHNER TP4-4141A024M is a TP series electromechanical safety switch with guard locking, order no. 084275, based on the open-circuit current principle: the guard is held locked while the 24 V AC/DC solenoid is energized and spring force unlocks it once power is cut (power to lock). Slow-action switching element 4141 provides 2 positively driven contacts for guard lock monitoring and 2 positively driven contacts for the door position, rated AC-15 4 A 230 V and DC-13 4 A 24 V. The reinforced thermoplastic housing has three M20 x 1.5 cable entries, an auxiliary release and IP67 protection for -20 to 55 °C. Locking force is 1300 N (F max) and 1000 N (F Zh), and the actuator is sold separately.
