EUCHNER TP3-2131A024M Industrial Sensor

Product overview

The EUCHNER TP3-2131A024M is a TP series electromechanical safety switch with guard locking, order no. 084142, built on the closed-circuit current principle: spring force keeps the guard locked and the 24 V AC/DC solenoid unlocks it (power to unlock). Slow-action switching element 2131 provides 2 positively driven contacts plus 1 NO contact for guard lock monitoring and 1 NC contact for the door position, rated AC-15 4 A 230 V and DC-13 4 A 24 V. The reinforced thermoplastic housing has three M20 x 1.5 cable entries, an auxiliary release on the front and IP67 protection, and it operates from -20 to 55 °C. Locking force is 1300 N (F max) and 1000 N (F Zh); the actuator is ordered separately.
