EUCHNER TP1-4131A024M Industrial Sensor

Product overview

The EUCHNER TP1-4131A024M is a TP series electromechanical safety switch with guard locking and no door monitoring contact. Guard locking follows the closed-circuit current principle: spring force keeps the guard locked until the 24 V AC/DC solenoid is energized (power to unlock), with locking forces of 1300 N (F max) and 1000 N (F Zh). Slow-action switching element 4131 provides 2 positively driven contacts plus 2 NO contacts for guard lock monitoring, rated AC-15 4 A 230 V and DC-13 4 A 24 V. The reinforced thermoplastic housing has 3 cable entries M20 x 1.5, an auxiliary release, IP67 protection and an ambient range of -20 to 55 °C; the actuator is ordered separately.
