WAGO 750-453 Four-Channel Analog Input Module

Product overview

The WAGO 750-453 is a 4-channel analog input module of the WAGO I/O System 750 for 0 … 20 mA current signals in single-ended connection. It resolves 12 bits with a typical conversion time of 10 ms, has an input resistance of max. 100 Ω, and the measurement error is 0.1 % of the upper-range value at 25 °C. Sensors connect as 4 x (2-wire), the 24 VDC field supply comes via the power jumper contacts and the module draws 65 mA from the system supply. It has 500 V system/field isolation, operates at 0 … +55 °C and measures (12 x 100 x 69.8) mm (W x H x D).
