OPTEX CS-30TAC CS Series Infrared Thermometer
- Brand
- OPTEX
- Model
- CS-30TAC
- GEARWELL SKU
- GWP-000021635
- Category
- Pressure, Flow & Temperature
Key specifications
- Analog output
- 4 to 20 mA
- Field of view
- ø30 / 500 mm (22:1)
- Response time
- 150 ms / 90%
- Control output
- Photo MOS FET x 2, 300 mA / 30 VDC
- Supply voltage
- 12 to 24 VDC ±10%
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | OPTEX CS-30TAC CS Series Infrared Thermometer |
|---|---|
| Brand | OPTEX |
| Model | CS-30TAC |
| Category | Pressure, Flow & Temperature |
| Analog output | 4 to 20 mA |
| Field of view | ø30 / 500 mm (22:1) |
| Response time | 150 ms / 90% |
| Control output | Photo MOS FET x 2, 300 mA / 30 VDC |
| Supply voltage | 12 to 24 VDC ±10% |
| Measurement range | -40 to 500 °C |
| Degree of protection | Sensor head IP69K, amplifier IP40 |
| Sensor head dimensions | M12 (ø14) x 34 mm |
| Sensing element / spectral response | Thermopile / 8 to 14 µm |
