DANFOSS 5113-B002-100-10-B160 MBT 5113 Thermocouple Temperature Sensor
- Brand
- DANFOSS
- Model
- 5113-B002-100-10-B160
- GEARWELL SKU
- GWP-000023756
- Category
- Pressure, Flow & Temperature
Key specifications
- Tolerance
- EN 60584-2 class 2
- Neck length
- 100 mm
- Transmitter
- Galvanically isolated, in raised cover
- Connection head
- B-head
- Protection tube
- AISI 316 Ti (W-Nr. 1.4571), ø24/ø14
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DANFOSS 5113-B002-100-10-B160 MBT 5113 Thermocouple Temperature Sensor |
|---|---|
| Brand | DANFOSS |
| Model | 5113-B002-100-10-B160 |
| Category | Pressure, Flow & Temperature |
| Tolerance | EN 60584-2 class 2 |
| Neck length | 100 mm |
| Transmitter | Galvanically isolated, in raised cover |
| Connection head | B-head |
| Protection tube | AISI 316 Ti (W-Nr. 1.4571), ø24/ø14 |
| Sensing element | 1 x NiCr-Ni, type K (-50 to 800 °C) |
| Insertion length | 100 mm |
| Transmitter range | 0 to 600 °C |
| Process connection | G 3/4 A |
| Degree of protection | IP65 (IEC 60529) |
