ABB 266DSHMSKD2A1V4L5B2 266DSH Differential Pressure Transmitter
- Brand
- ABB
- Model
- 266DSHMSKD2A1V4L5B2
- GEARWELL SKU
- GWP-000024257
- Category
- Pressure, Flow & Temperature
Key specifications
- Base model
- 266DSH differential pressure transmitter, base accuracy 0.06 %
- Output (code 1)
- HART and 4 to 20 mA, advanced functionality
- Options V4 / L5 / B2
- Hastelloy C-276 drain/vent valve on process axis / integral LCD with TTG keypad / AISI 316 L ss pipe-wall bracket
- Application (code S)
- Differential measurement at standard static pressure
- Bolts / gasket (code 2)
- AISI 316 ss / PTFE
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | ABB 266DSHMSKD2A1V4L5B2 266DSH Differential Pressure Transmitter |
|---|---|
| Brand | ABB |
| Model | 266DSHMSKD2A1V4L5B2 |
| Category | Pressure, Flow & Temperature |
| Base model | 266DSH differential pressure transmitter, base accuracy 0.06 % |
| Output (code 1) | HART and 4 to 20 mA, advanced functionality |
| Options V4 / L5 / B2 | Hastelloy C-276 drain/vent valve on process axis / integral LCD with TTG keypad / AISI 316 L ss pipe-wall bracket |
| Application (code S) | Differential measurement at standard static pressure |
| Bolts / gasket (code 2) | AISI 316 ss / PTFE |
| Process flanges (code D) | Hastelloy C-276, horizontal, 1/4 in.-18 NPT-f direct |
| Sensor span limits (code M) | 24 to 2400 kPa |
| Diaphragm / fill fluid (code K) | Hastelloy C-276 / silicone oil |
| Housing / electrical connection (code A) | Aluminium alloy barrel, 1/2 in.-14 NPT |
