OMRON E5CK-AA1-500 E5CK Digital Controller
- Brand
- OMRON
- Model
- E5CK-AA1-500
- GEARWELL SKU
- GWP-000024792
- Category
- Pressure, Flow & Temperature
Key specifications
- Inputs
- Thermocouple, Pt100/JPt100, 4-20 mA, 0-20 mA, 1-5 V, 0-5 V, 1-10 V
- Control method
- ON/OFF or 2-PID with auto-tuning
- Auxiliary output
- SPST-NO, 1 A at 250 VAC
- Front protection
- IP66 / NEMA4 (indoor)
- Model description
- Base unit with terminal cover (without output unit)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | OMRON E5CK-AA1-500 E5CK Digital Controller |
|---|---|
| Brand | OMRON |
| Model | E5CK-AA1-500 |
| Category | Pressure, Flow & Temperature |
| Inputs | Thermocouple, Pt100/JPt100, 4-20 mA, 0-20 mA, 1-5 V, 0-5 V, 1-10 V |
| Control method | ON/OFF or 2-PID with auto-tuning |
| Auxiliary output | SPST-NO, 1 A at 250 VAC |
| Front protection | IP66 / NEMA4 (indoor) |
| Model description | Base unit with terminal cover (without output unit) |
| Supply voltage options | AC100-240 / AC/DC24 (specify on order) |
