MKS 728A-28375 Baratron 728A Heated Absolute Capacitance Manometer
- Brand
- MKS
- Model
- 728A-28375
- GEARWELL SKU
- GWP-000024915
- Category
- Pressure, Flow & Temperature
Key specifications
- Accuracy
- 0.50% of reading (10-1000 Torr); 1.0% of reading (<10 Torr)
- Configuration
- Absolute, single-ended, heated to 100 °C
- Output signal
- 0-10 VDC into >10 kohm
- Response time
- < 75 ms
- Power required
- ±15 VDC ±5% @ 400 mA max
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | MKS 728A-28375 Baratron 728A Heated Absolute Capacitance Manometer |
|---|---|
| Brand | MKS |
| Model | 728A-28375 |
| Category | Pressure, Flow & Temperature |
| Accuracy | 0.50% of reading (10-1000 Torr); 1.0% of reading (<10 Torr) |
| Configuration | Absolute, single-ended, heated to 100 °C |
| Output signal | 0-10 VDC into >10 kohm |
| Response time | < 75 ms |
| Power required | ±15 VDC ±5% @ 400 mA max |
| Wetted material | Inconel |
| Code suffix "-28375" | as collected; not listed in the official model-number table |
| Full scale range options | 1 / 2 / 10 / 30 / 50 / 100 / 200 / 500 / 1000 Torr (specify on order) |
| Electrical connector options | 15-pin or 9-pin D-sub (specify on order) |
