FOTEK FR-1-110V FR Series Floatless Level Relay, 110 V AC
- Brand
- FOTEK
- Model
- FR-1-110V
- GEARWELL SKU
- GWP-000024964
- Category
- Pressure, Flow & Temperature
Key specifications
- Type
- Standard (FR-1)
- Output
- Relay, 5 A / 250 V AC
- Ambient
- -20 to +60 C, 35-85% RH
- Dimension
- 40 x 50 mm
- Sensitivity
- ON < 30 kOhm, OFF > 60 kOhm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK FR-1-110V FR Series Floatless Level Relay, 110 V AC |
|---|---|
| Brand | FOTEK |
| Model | FR-1-110V |
| Category | Pressure, Flow & Temperature |
| Type | Standard (FR-1) |
| Output | Relay, 5 A / 250 V AC |
| Ambient | -20 to +60 C, 35-85% RH |
| Dimension | 40 x 50 mm |
| Sensitivity | ON < 30 kOhm, OFF > 60 kOhm |
| Power supply | 110 V AC (code -110V); series: 110 / 230 / 380 V AC +/-20%, 50/60 Hz |
| Response time | ON < 80 ms, OFF < 160 ms |
| Electrode voltage | 14 V AC |
| Current consumption | 3 VA max. |
