HONEYWELL DC3200-E0-2A0R-160-00000-00-0 UDC3200 Digital Controller

Key specifications

Evidence: Honeywell 51-51-16U-80 Issue 16 model selection guide (hosted at literature.neuco.com)
Table I: E0: Output #1 electromechanical relay (5 A Form C); no additional outputs or alarms
Table V: 00: Product information on CD (all languages); no certificate
Table VI: 0: No selection
Table II: 2A0R: RS-485 Modbus plus auxiliary output/digital inputs; Math option; reserved 0; infrared interface included

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	HONEYWELL DC3200-E0-2A0R-160-00000-00-0 UDC3200 Digital Controller
Brand	HONEYWELL
Model	DC3200-E0-2A0R-160-00000-00-0
Category	Pressure, Flow & Temperature
Evidence	Honeywell 51-51-16U-80 Issue 16 model selection guide (hosted at literature.neuco.com)
Table I: E0	Output #1 electromechanical relay (5 A Form C); no additional outputs or alarms
Table V: 00	Product information on CD (all languages); no certificate
Table VI: 0	No selection
Table II: 2A0R	RS-485 Modbus plus auxiliary output/digital inputs; Math option; reserved 0; infrared interface included
Table III: 160	Input 1 TC, RTD, mV, 0-5 V, 1-5 V; input 2 carbon, oxygen or dewpoint (provides 2 inputs)
Table IV: 00000	CE approval (standard); no tag; no future options
Key number DC3200	Digital controller for use with 90 to 250 Vac power
