HONEYWELL STD924-E1A-00000-1C ST 3000 DP Pressure Transmitter

Key specifications

Evidence: Honeywell 34-ST-03-65 (Jan 2013) incl. model selection guide 34-ST-16U-24 Issue 55 (hosted at pages.mtu.edu)
Key number: STD924: 0-4 to 0-400 inH2O / 0-10 to 0-1,000 mbar span, body rating 4,500 psi (310 bar)
Approval 1C: FM Approvals: explosion proof Class I Div 1 Groups A,B,C,D; dust-ignitionproof Class II, III Div 1; non-incendive; intrinsically safe
Supply voltage: 10.8 to 42.4 Vdc at terminals V DC
Table II 00000: no selection

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	HONEYWELL STD924-E1A-00000-1C ST 3000 DP Pressure Transmitter
Brand	HONEYWELL
Model	STD924-E1A-00000-1C
Category	Pressure, Flow & Temperature
Evidence	Honeywell 34-ST-03-65 (Jan 2013) incl. model selection guide 34-ST-16U-24 Issue 55 (hosted at pages.mtu.edu)
Key number	STD924: 0-4 to 0-400 inH2O / 0-10 to 0-1,000 mbar span, body rating 4,500 psi (310 bar)
Approval 1C	FM Approvals: explosion proof Class I Div 1 Groups A,B,C,D; dust-ignitionproof Class II, III Div 1; non-incendive; intrinsically safe
Supply voltage	10.8 to 42.4 Vdc at terminals V DC
Table II 00000	no selection
Turndown ratio	100 to 1
Accuracy (analog mode)	+/-0.075% of calibrated span or URV, whichever is greater
Fill fluid (Table I) 1	DC 200 silicone
Meter body (Table I) E	316 SS process heads, 316 SS vent/drain, 316L SS barrier diaphragms
Process head configuration (Table I) A	1/4 NPT
