IFM SI6700 Flow Monitor
- Brand
- IFM
- Model
- SI6700
- GEARWELL SKU
- GWP-000002727
- Category
- Industrial Automation Parts
Key specifications
- Protection
- IP 67; IP 69K
- Product type
- Flow monitor
- Output signal
- switching signal
- Output function
- normally open / closed; (configurable)
- Electrical design
- PNP
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm SI6700 (SIR11ABBFPKG/US-100-IPF) is a flow monitor. The flow switch point can be set over 3…300 cm/s, with the greatest sensitivity at 3…100 cm/s and a response time of 1…10 s. The probe is 38 mm long and 7.7 mm in diameter. The process connection is a G 1 external thread with Aseptoflex Vario sealing contour, the pressure rating is 30 bar, the wetted parts are stainless steel (1.4435 / 316L) and the medium temperature range is -25…95 °C (up to 140 °C for SIP). It provides 1 switching output (PNP), with the switching output configurable as normally open or normally closed and rated at 250 mA, runs on 19…36 V DC and connects through an M12 connector (A-coded, 4 gold-plated contacts). The unit is Ø 50 mm and 137 mm long and is rated IP67 and IP69K for -25…60 °C ambient.
Technical reference
| Product name | IFM SI6700 Flow Monitor |
|---|---|
| Brand | IFM |
| Model | SI6700 |
| Category | Industrial Automation Parts |
| Protection | IP 67; IP 69K |
| Product type | Flow monitor |
| Output signal | switching signal |
| Output function | normally open / closed; (configurable) |
| Electrical design | PNP |
| Operating voltage | 19...36 V DC |
| Process connection | threaded connection G 1 external thread Aseptoflex Vario |
| Current consumption | < 60 mA |
