IFM PT5504 Pressure Transmitter
- Brand
- IFM
- Model
- PT5504
- GEARWELL SKU
- GWP-000003348
- Category
- Pressure, Flow & Temperature
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm PT5504 (PT-010-SEG14-A-ZVG/US) is a pressure transmitter for liquids and gases. It measures relative pressure over 0…10 bar (0…145 psi), with a pressure rating of 25 bar and a minimum burst pressure of 300 bar. The process connection is a G 1/4 external thread (DIN EN ISO 1179-2), the wetted parts are stainless steel (630/1.4542/17-4 PH), and the permitted medium temperature is -40…125 °C. It provides 1 analog output (4…20 mA), runs on 8…32 V DC and connects through an M12 connector (A-coded, 2 contacts). ifm specifies characteristic deviation < ± 0.8 % of span and repeatability < ± 0.05 % of span. The sensor is rated IP67 and IP69K for -40…100 °C ambient.
Technical reference
| Product name | IFM PT5504 Pressure Transmitter |
|---|---|
| Brand | IFM |
| Model | PT5504 |
| Category | Pressure, Flow & Temperature |
