IFM PG2454 Pressure Sensor with Analog Display
- Brand
- IFM
- Model
- PG2454
- GEARWELL SKU
- GWP-000001334
- Category
- Industrial Automation Parts
Key specifications
- Protection
- IP 67; IP 69K
- Product type
- Pressure sensor with analog display
- Output signal
- switching signal; analog signal; (configurable)
- Output function
- normally open / closed; (configurable)
- Electrical design
- PNP/NPN
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm PG2454 (PG-010-REB12-MFRKG/US/ /P) is a pressure sensor with analog display for liquids and gases. It measures relative pressure and vacuum over -1…10 bar (-14.4…145 psi), with a pressure rating of 50 bar and a minimum burst pressure of 150 bar. The process connection is a G 1/2 external thread, the wetted parts are ceramics (Al2O3), FKM and stainless steel (1.4404 / 316L), and the permitted medium temperature is -25…80 °C. It provides 1 switching output (PNP/NPN) and 1 analog output (4…20 mA), runs on 18…32 V DC and connects through an M12 connector (A-coded, 4 gold-plated contacts). ifm specifies characteristic deviation < ± 0.25 % of span and repeatability < ± 0.1 % of span. The sensor is rated IP67 and IP69K for -20…80 °C ambient.
Technical reference
| Product name | IFM PG2454 Pressure Sensor with Analog Display |
|---|---|
| Brand | IFM |
| Model | PG2454 |
| Category | Industrial Automation Parts |
| Protection | IP 67; IP 69K |
| Product type | Pressure sensor with analog display |
| Output signal | switching signal; analog signal; (configurable) |
| Output function | normally open / closed; (configurable) |
| Electrical design | PNP/NPN |
| Operating voltage | 18...32 V DC |
| Process connection | threaded connection G 1/2 external thread |
| Current consumption | < 70; (24 V) mA |
