IFM OK5008 Fiber-Optic Amplifier
- Brand
- IFM
- Model
- OK5008
- GEARWELL SKU
- GWP-000003505
- Category
- Industrial Automation Parts
Key specifications
- Dimensions
- 50 x 19 x 35 mm
- Protection
- IP 65
- Product type
- Fiber-optic amplifier
- Output function
- light-on/dark-on mode; (programmable)
- Electrical design
- PNP
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm OK5008 (OKF-FPKG/US-100-DPF) is a fiber-optic amplifier in a rectangular housing measuring 50 x 19 x 35 mm. ifm specifies a range of 0…40 mm as a diffuse reflection sensor and a range of 0…0.12 m as a through-beam sensor. It works with red light (660 nm). It has 1 PNP switching output. The switching output is programmable for light-on or dark-on mode, switches at up to 120 Hz and carries up to 250 mA. It runs on 10…36 V DC and connects through an M12 connector (A-coded, 4 contacts). It is rated IP65 for -25…60 °C ambient.
Technical reference
| Product name | IFM OK5008 Fiber-Optic Amplifier |
|---|---|
| Brand | IFM |
| Model | OK5008 |
| Category | Industrial Automation Parts |
| Dimensions | 50 x 19 x 35 mm |
| Protection | IP 65 |
| Product type | Fiber-optic amplifier |
| Output function | light-on/dark-on mode; (programmable) |
| Electrical design | PNP |
| Operating voltage | 10...36 V DC |
| Ambient temperature | -25...60 °C |
| Current consumption | 30; ((24 V)) mA |
