IFM OO5004 OOF-FPKG/M12/GL2 Fiber-optic amplifier
- Brand
- IFM
- Model
- OO5004
- GEARWELL SKU
- GWP-000012467
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Range
- < 0.4; (Through-beam sensor) m
- Housing
- rectangular
- Type of light
- red light
- Output function
- light-on/dark-on mode; (programmable)
- Electrical design
- PNP
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm OO5004 (OOF-FPKG/M12/GL2) is a fiber-optic amplifier in a rectangular housing measuring 79.9 x 76.9 x 70.7 mm. ifm specifies a range of 0…200 mm as a diffuse reflection sensor and a range of up to 0.4 m as a through-beam sensor. It works with red light (630 nm). It has 1 PNP switching output. The switching output is programmable for light-on or dark-on mode, switches at up to 2700 Hz and carries up to 200 mA. It runs on 12…36 V DC and connects through an M12 connector (A-coded, 8 contacts). It has an ABS housing and is rated IP65 for -20…60 °C ambient.
Technical reference
| Product name | IFM OO5004 OOF-FPKG/M12/GL2 Fiber-optic amplifier |
|---|---|
| Brand | IFM |
| Model | OO5004 |
| Category | Proximity & Photoelectric Sensors |
| Range | < 0.4; (Through-beam sensor) m |
| Housing | rectangular |
| Type of light | red light |
| Output function | light-on/dark-on mode; (programmable) |
| Electrical design | PNP |
| Operating voltage | 12...36 DC V |
| Current consumption | 50; ((24 V)) mA |
| Switching frequency DC | 2700 Hz |
