IFM KTE302 KTEEFOEMMFRKG/2M/IO Capacitive Touch Sensor
- Brand
- IFM
- Model
- KTE302
- GEARWELL SKU
- GWP-000008438
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Housing
- threaded type
- Dimensions
- M22 x 1 / L = 39.6 mm
- Protection
- IP 65; IP 67 (IP 69K on the front)
- Output function
- normally open / normally closed (parameterisable)
- Electrical design
- PNP/NPN (parameterisable)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm KTE302 (KTEEFOEMMFRKG/2M/IO) is a capacitive touch sensor in an M22 x 1 threaded housing 39.6 mm long. It is operated by touch on the actuating surface, with a response time of 64 ms. Its switching behavior can be set to dynamic, static, bistable and combination, and it has 2 inputs to IEC 61131-2 type 3 and is UV resistant. The PNP/NPN switching output is configurable as normally open or normally closed, rated at 200 mA, on 8…32 V DC. The sensor has a stainless steel housing and connects through a 2 m PUR cable with 5 x 0.34 mm² conductors, and is rated IP65 and IP67 (IP69K on the front) for -30…65 °C ambient. Supplied with an M22 lock nut, a transparent symbol disc, a symbol sticker, a gasket and an O-ring.
Technical reference
| Product name | IFM KTE302 KTEEFOEMMFRKG/2M/IO Capacitive Touch Sensor |
|---|---|
| Brand | IFM |
| Model | KTE302 |
| Category | Proximity & Photoelectric Sensors |
| Housing | threaded type |
| Dimensions | M22 x 1 / L = 39.6 mm |
| Protection | IP 65; IP 67 (IP 69K on the front) |
| Output function | normally open / normally closed (parameterisable) |
| Electrical design | PNP/NPN (parameterisable) |
| Operating voltage | 8...32 DC V |
| Ambient temperature | -30...65 °C |
| Communication interface | IO-Link |
