IFM CR0232 Mobile Machine Controller
- Brand
- IFM
- Model
- CR0232
- GEARWELL SKU
- GWP-000000150
- Category
- PLCs & I/O
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm CR0232 (R360/ExtendedController/32) is a programmable controller for mobile machines, programmable to IEC 61131-3. ifm lists 80 inputs and outputs in total: 32 digital, 32 analog (0…20 mA or 0…32 V) and 32 frequency inputs, and 48 digital outputs, with 32 PWM, 32 current-controlled PWM-I and 4 H-bridge outputs listed. It has four CAN interfaces, one RS232 interface and one USB interface. It runs on 10…32 V DC, measures 153 x 277 x 43 mm and is screw mounted. ifm notes that this model should not be used for new projects.
Technical reference
| Product name | IFM CR0232 Mobile Machine Controller |
|---|---|
| Brand | IFM |
| Model | CR0232 |
| Category | PLCs & I/O |
