IFM ANT513 HF RFID Read/Write Head

Product overview

The ifm ANT513 (DTRHF MCRWIDUS03) is an HF RFID read/write head working at 13.56 MHz to ISO 15693, for detecting objects on transport equipment; it is supplied and read through a DTE10x evaluation unit. ifm gives a read/write distance of up to 60 mm to reference tag E80370, and a minimum spacing of 250 mm front and 300 mm side between heads. It has a 40 x 40 x 54 mm PA housing with a sensing face that can be set to 5 positions, connects through an M12 connector (A-coded, 4 contacts) and is rated IP67 and IP69K for -20…60 °C ambient.
