IFM CR1083 Programmable Human Machine Interface

Product overview

The ifm CR1083 (R360/PDM NG/DialogDisplay/C) is a programmable display for mobile machines, programmable to IEC 61131-3, with a 7" LED-backlit color display of 800 x 480 pixels and eight freely programmable backlit function keys. It has four CAN interfaces, one Ethernet interface, two USB interfaces and two analog video inputs (CVBS), plus one digital input, one analog input (0…20 mA or 0…32 V), one digital output and a real-time clock. It runs on 10…32 V DC with a power consumption of 7.2 W, measures 157 x 192 x 53.6 mm and mounts in a panel or on a surface.
