IFM AC5291 AS-Interface ClassicLine Module
- Brand
- IFM
- Model
- AC5291
- GEARWELL SKU
- GWP-000008619
- Category
- PLCs & I/O
Key specifications
- Housing
- rectangular
- Materials
- PA; piercing contacts: CuSn6 nickel-plated and tin-plated
- Dimensions
- 103 x 45 x 44.7 mm
- Protection
- IP 67
- Operating voltage
- 26.5...31.6 DC V
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm AC5291 (ClassicLine 4DI-Y IP67) is an AS-Interface ClassicLine module with quick mounting technology for field installation. It has four digital inputs, with PNP inputs powered from AS-i. On the AS-i side it supports AS-i versions 2.11 and 3.0 with slave profile S-0.A.E and extended (A/B) addressing, and it works with AS-i masters of profile M2, M3 and M4. It runs on 26.5…31.6 V DC from the AS-i line, drawing up to 250 mA. The housing measures 103 x 45 x 44.7 mm and is made of PA. It connects to the AS-i flat cable by quick mounting and mounts on a TH35 DIN rail, has an M12 socket and is rated IP67 for -25…70 °C ambient. ifm notes that the module also distributes the AS-i voltage. Supplied with the lower part and a flat cable blank for the unused cable entry.
Technical reference
| Product name | IFM AC5291 AS-Interface ClassicLine Module |
|---|---|
| Brand | IFM |
| Model | AC5291 |
| Category | PLCs & I/O |
| Housing | rectangular |
| Materials | PA; piercing contacts: CuSn6 nickel-plated and tin-plated |
| Dimensions | 103 x 45 x 44.7 mm |
| Protection | IP 67 |
| Operating voltage | 26.5...31.6 DC V |
| Ambient temperature | -25...70 °C |
| Number of digital inputs | 4 |
| Max. current consumption from AS-i | 250 mA |
