IFM AC2032 AS-Interface Universal Input Module
- Brand
- IFM
- Model
- AC2032
- GEARWELL SKU
- GWP-000006760
- Category
- PLCs & I/O
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm AC2032 (EMS/Module/4DI/CCT) is an AS-Interface universal module for field installation. It has four digital inputs, with PNP inputs powered from AS-i. On the AS-i side it uses slave profile S-0.0.F, and it works with AS-i masters of profile M2, M3 and M4. It runs on 26.5…31.6 V DC from the AS-i line, drawing up to 200 mA. The housing measures 102 x 45 x 50 mm and is made of PA 6-GF30. It fits an FC or SC lower part and is rated IP65 for -25…60 °C ambient.
Technical reference
| Product name | IFM AC2032 AS-Interface Universal Input Module |
|---|---|
| Brand | IFM |
| Model | AC2032 |
| Category | PLCs & I/O |
