GE IC693MDL940H Series 90-30 16-Point 2 A Relay Output Module
- Brand
- GE
- Model
- IC693MDL940H
- GEARWELL SKU
- GWP-000025758
- Category
- PLCs & I/O
Key specifications
- Outputs
- 16 normally-open relays, four groups of four
- Evidence
- GE Fanuc GFK-0898F Series 90-30 PLC I/O Module Specifications page (hosted at qualitrol.com)
- Isolation
- 1500 V field to logic, 500 V between groups
- Maximum load
- 2 A pilot duty per output, 4 A per common
- Minimum load
- 10 mA
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC693MDL940H Series 90-30 16-Point 2 A Relay Output Module |
|---|---|
| Brand | GE |
| Model | IC693MDL940H |
| Category | PLCs & I/O |
| Outputs | 16 normally-open relays, four groups of four |
| Evidence | GE Fanuc GFK-0898F Series 90-30 PLC I/O Module Specifications page (hosted at qualitrol.com) |
| Isolation | 1500 V field to logic, 500 V between groups |
| Maximum load | 2 A pilot duty per output, 4 A per common |
| Minimum load | 10 mA |
| Response time | 15 ms maximum on/off |
| Catalog number | IC693MDL940 |
| Revision suffix | H (as collected; hardware/firmware revision, not part of the catalog number) |
| Operating voltage | 5 to 30 VDC / 5 to 250 VAC, 50/60 Hz |
| Power consumption | 7 mA from 5 V bus, 135 mA from relay 24 V bus (all outputs on) |
