GE IC693MDL645 Series 90-30 24 VDC Pos/Neg Logic Input Module 16 Point
- Brand
- GE
- Model
- IC693MDL645
- GEARWELL SKU
- GWP-000026591
- Category
- PLCs & I/O
Key specifications
- Evidence
- GE Fanuc GFK-0898F Series 90-30 PLC I/O Module Specifications, IC693MDL645 pages (hosted at qualitrol.com)
- Isolation
- 1500 V field side to logic side
- Input current
- 7 mA typical at rated voltage
- Rated voltage
- 24 VDC, positive or negative logic
- Response time
- 7 ms typical on / off
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC693MDL645 Series 90-30 24 VDC Pos/Neg Logic Input Module 16 Point |
|---|---|
| Brand | GE |
| Model | IC693MDL645 |
| Category | PLCs & I/O |
| Evidence | GE Fanuc GFK-0898F Series 90-30 PLC I/O Module Specifications, IC693MDL645 pages (hosted at qualitrol.com) |
| Isolation | 1500 V field side to logic side |
| Input current | 7 mA typical at rated voltage |
| Rated voltage | 24 VDC, positive or negative logic |
| Response time | 7 ms typical on / off |
| Catalog number | IC693MDL645 |
| On-state voltage | 11.5 to 30 VDC |
| Inputs per module | 16 (one group with a single common) |
| Power consumption | 80 mA from 5 V bus; 125 mA from isolated 24 V bus or user supply |
| Input voltage range | 0 to +30 VDC |
