EUCHNER NP1-628AS-M NP Safety Switch
- Brand
- EUCHNER
- Model
- NP1-628AS-M
- GEARWELL SKU
- GWP-000000840
- Category
- Industrial Automation Parts
Key specifications
- Mounting
- According to DIN EN 50047
- Cable entry
- 1 × M20 × 1.5
- Product type
- NP safety switch
- Approach direction
- Horizontal and vertical, adjustable in 90° steps
- Switching principle
- Slow-action switching contact
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The EUCHNER NP1-628AS-M is an NP series electromechanical safety switch without guard locking, mounted according to DIN EN 50047 and operated by a separately ordered actuator. Switching element 628 provides 1 NC + 1 NO slow-action contacts rated AC-15 4 A 230 V and DC-13 4 A 24 V, with a 4 A gG control circuit fuse. The reinforced thermoplastic housing has a cable entry M20 x 1.5 and IP67 protection, and the switch operates from -20 to +80 °C. The actuating head can be repositioned to change the approach direction.
Technical reference
| Product name | EUCHNER NP1-628AS-M NP Safety Switch |
|---|---|
| Brand | EUCHNER |
| Model | NP1-628AS-M |
| Category | Industrial Automation Parts |
| Mounting | According to DIN EN 50047 |
| Cable entry | 1 × M20 × 1.5 |
| Product type | NP safety switch |
| Approach direction | Horizontal and vertical, adjustable in 90° steps |
| Switching principle | Slow-action switching contact |
| Contact configuration | 1 positively driven NC + 1 NO |
