EUCHNER MGB-L2H-ARA-R-105786 Guard Locking Set

Product overview

The EUCHNER MGB-L2H-ARA-R-105786 is an MGB multifunctional gate box set for a door hinged on the right, made up of handle module MGB-H-AA1A1-R-100464 and locking module MGB-L2-ARA-AA1A1-M-104303. Guard locking follows the open-circuit current principle: the locking arm is held locked by solenoid force and released by spring force when the solenoid is switched off, with a locking force F Zh of 2000 N. The unicode transponder-coded locking module can be connected in series with other AR devices and has two p-switching semiconductor safety outputs rated DC-13 24V 200mA plus monitoring outputs OD, OT, OL and OI, powered from 24 V DC through cable entries M20x1.5. The housings combine fiber glass reinforced plastic, nickel-plated die-cast zinc and stainless steel, with IP65 protection, an ambient range of -20 to 55 °C and PL e, category 4 for guard position and guard lock monitoring.
