EUCHNER MGB-L1H-APA-R-121369 Safety Switch
- Brand
- EUCHNER
- Model
- MGB-L1H-APA-R-121369
- GEARWELL SKU
- GWP-000003872
- Category
- Industrial Automation Parts
Key specifications
- Housing
- Fiber glass reinforced plastic, nickel-plated die-cast zinc, stainless steel
- Gross weight
- 2,141kg
- Output current
- max. 50 mA
- Connection type
- Plug connector RC18 (X6)
- LED power supply
- 24 V DC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The EUCHNER MGB-L1H-APA-R-121369 is an MGB locking set with guard locking and guard lock monitoring, order no. 121369, in which spring force holds the locking arm and solenoid force unlocks it (closed-circuit current principle). It combines handle module MGB-H-AA1A1-R-100464 with locking module MGB-L1-APA-AP4A1-S1-R-121368, which carries an emergency stop with 2 positively driven contacts and 3 illuminated pushbuttons with 1 NO contact each, plus a lens set in 5 colors. The unicode system runs on 24 V DC, connects through an RC18 plug connector and reaches PL e, category 4 for guard locking control, guard position and guard lock monitoring. Locking force F Zh is 2000 N, and the housing is rated IP65 for -20 to 55 °C, for a door hinged on the right.
Technical reference
| Product name | EUCHNER MGB-L1H-APA-R-121369 Safety Switch |
|---|---|
| Brand | EUCHNER |
| Model | MGB-L1H-APA-R-121369 |
| Category | Industrial Automation Parts |
| Housing | Fiber glass reinforced plastic, nickel-plated die-cast zinc, stainless steel |
| Gross weight | 2,141kg |
| Output current | max. 50 mA |
| Connection type | Plug connector RC18 (X6) |
| LED power supply | 24 V DC |
| Locking force F Zh | 2000 N |
| Ambient temperature | -20 ... 55 °C |
| Degree of protection | IP65 |
