EUCHNER MGB-L1HB-PNA-R-121832 Industrial Automation Part
- Brand
- EUCHNER
- Model
- MGB-L1HB-PNA-R-121832
- GEARWELL SKU
- GWP-000002556
- Category
- Industrial Automation Parts
Key specifications
- Housing
- Fiber glass reinforced plastic, nickel-plated die-cast zinc, stainless steel
- Gross weight
- 5,64kg
- Locking force F Zh
- 2000 N
- Ambient temperature
- -20 ... 55 °C
- Current consumption
- max. 500 mA
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The EUCHNER MGB-L1HB-PNA-R-121832 is an MGB multifunctional gate box set for a door hinged on the right, combining handle module MGB-H-AA1A2-R-106049 with evaluation and bus module MGB-L1B-PNA-R-121831, pre-assembled on mounting plates. Guard locking works by spring force on the closed-circuit current principle (power to unlock), with a locking force F Zh of 2000 N. The bus module connects to Profinet with the PROFIsafe safety protocol through push-pull power and push-pull RJ45 connectors, has an integrated Profinet RT switch and carries 2 illuminated pushbuttons, running on 24 V DC. The unicode transponder-coded system reaches PL e, category 4, the locking module is rated IP54 and the ambient range is -20 to 55 °C.
Technical reference
| Product name | EUCHNER MGB-L1HB-PNA-R-121832 Industrial Automation Part |
|---|---|
| Brand | EUCHNER |
| Model | MGB-L1HB-PNA-R-121832 |
| Category | Industrial Automation Parts |
| Housing | Fiber glass reinforced plastic, nickel-plated die-cast zinc, stainless steel |
| Gross weight | 5,64kg |
| Locking force F Zh | 2000 N |
| Ambient temperature | -20 ... 55 °C |
| Current consumption | max. 500 mA |
| Degree of protection | IP65 |
| EMC protection requirements | In accordance with EN 61000-4 and EN 61326-3-1 |
| Rated impulse voltage U imp | 0.5 kV |
