DELTA TP04P-32TP1R 4-line text panel HMI with built-in PLC
- Brand
- DELTA
- Model
- TP04P-32TP1R
- GEARWELL SKU
- GWP-000014281
- Category
- HMIs & Industrial PCs
Key specifications
- Resolution
- 192 x 64 pixels
- Output type
- Relay
- Screen type
- STN-LCD, monochrome
- Display size
- 4.1 in
- Flash memory
- 1M bytes
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Delta TP04P-32TP1R is a TP04P 4-line text panel HMI with a built-in PLC based on the DVP-SS2 core, with 8 k steps of program capacity and 5k words of D devices. The 4.1" monochrome STN-LCD shows 192 x 64 pixels, and the front has 17 function keys including 0 ~ 9 numeric keys; flash memory is 1 M bytes. This model has 16 digital inputs and 16 relay outputs, plus 2 sets of 10 kHz high-speed pulse input. It offers USB for program upload and download, two RS-485 ports with Modbus ASCII/RTU, and a built-in real time clock; it is programmed with TPEditor.
Technical reference
| Product name | DELTA TP04P-32TP1R 4-line text panel HMI with built-in PLC |
|---|---|
| Brand | DELTA |
| Model | TP04P-32TP1R |
| Category | HMIs & Industrial PCs |
| Resolution | 192 x 64 pixels |
| Output type | Relay |
| Screen type | STN-LCD, monochrome |
| Display size | 4.1 in |
| Flash memory | 1M bytes |
| Program capacity | 8k steps / D device 5k words |
| Serial COM ports | USB & RS-485 |
| Operating voltage | +24 (-10% ~ +20%) VDC |
