DELTA TP70P-21EX1R TP70P Touch Panel HMI with Built-in PLC
- Brand
- DELTA
- Model
- TP70P-21EX1R
- GEARWELL SKU
- GWP-000029873
- Category
- HMIs & Industrial PCs
Key specifications
- CPU
- 32-bit ARM Cortex-M4 MCU
- Resolution
- 800 x 480 pixels
- Analog input
- 2 channels current (12-bit)
- Screen/Color
- 7" TFT LCD (65535 colors)
- Analog output
- 1 channel current (12-bit)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELTA TP70P-21EX1R TP70P Touch Panel HMI with Built-in PLC |
|---|---|
| Brand | DELTA |
| Model | TP70P-21EX1R |
| Category | HMIs & Industrial PCs |
| CPU | 32-bit ARM Cortex-M4 MCU |
| Resolution | 800 x 480 pixels |
| Analog input | 2 channels current (12-bit) |
| Screen/Color | 7" TFT LCD (65535 colors) |
| Analog output | 1 channel current (12-bit) |
| Supply voltage | 24 V DC (-15%~20%) |
| Digital inputs / outputs | X0~X7 (8) / Y0~Y7 (8) |
| Temperature input (Pt100) | 2 channels (16-bit) |
