BECKHOFF EL9100 EtherCAT Potential Supply Terminal
- Brand
- BECKHOFF
- Model
- EL9100
- GEARWELL SKU
- GWP-000007142
- Category
- PLCs & I/O
Key specifications
- Power LED
- green
- Technology
- potential supply terminal
- Current load
- ≤ 10 A
- Renewed infeed
- yes
- Nominal voltage
- 24 V DC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
Beckhoff EL9100 is a 24 V DC potential supply terminal for EtherCAT, used to feed in a new field supply of up to 10 A to the power contacts within a terminal station. A green LED shows the supply status. Check the full order number, including any suffix, on the terminal when requesting a quote.
Technical reference
| Product name | BECKHOFF EL9100 EtherCAT Potential Supply Terminal |
|---|---|
| Brand | BECKHOFF |
| Model | EL9100 |
| Category | PLCs & I/O |
| Power LED | green |
| Technology | potential supply terminal |
| Current load | ≤ 10 A |
| Renewed infeed | yes |
| Nominal voltage | 24 V DC |
| Electrical isolation | 500 V (E-bus/field potential) |
| Bit width in the process image | 0 |
| Connection facility to additional power contact | 1 |
