BECKHOFF EL7411 EtherCAT 1-Channel BLDC Motor Terminal
- Brand
- BECKHOFF
- Model
- EL7411
- GEARWELL SKU
- GWP-000007140
- Category
- PLCs & I/O
Key specifications
- Load type
- BLDC
- Technology
- compact drive technology
- Number of inputs
- 2 x end position, 1 x encoder, 1 x fan diag, 3 x Hall effect sensor
- Number of channels
- 1
- Output current (rms)
- 4.5 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
Beckhoff EL7411 is a 1-channel BLDC motor terminal for EtherCAT at 8 to 48 V DC, delivering 4.5 A rms (9 A peak for 1 s), or up to 8 A rms with the ZB8610 fan cartridge. It has inputs for an incremental encoder, Hall sensors and two end positions. Check the full order number, including any suffix, on the terminal when requesting a quote.
Technical reference
| Product name | BECKHOFF EL7411 EtherCAT 1-Channel BLDC Motor Terminal |
|---|---|
| Brand | BECKHOFF |
| Model | EL7411 |
| Category | PLCs & I/O |
| Load type | BLDC |
| Technology | compact drive technology |
| Number of inputs | 2 x end position, 1 x encoder, 1 x fan diag, 3 x Hall effect sensor |
| Number of channels | 1 |
| Output current (rms) | 4.5 A |
| Supply voltage power | 8…48 V DC (external) |
| Connection technology | direct motor connection + feedback |
| Supply voltage electronics | 24 V DC (via power contacts) |
