BECKHOFF EL6022 EtherCAT 2-Channel Serial Interface Terminal
- Brand
- BECKHOFF
- Model
- EL6022
- GEARWELL SKU
- GWP-000008099
- Category
- PLCs & I/O
Key specifications
- Interfaces
- 2 x RS422/RS485
- Cable length
- approx. 1000 m twisted pair
- Power supply
- via the E-bus
- Cable impedance
- 120 Ω
- Transmission rate
- 300…115,200 baud; default: 9600 baud, 8 data bits, no parity and one stop bit
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
Beckhoff EL6022 is a 2-channel RS422/RS485 serial interface terminal for EtherCAT with two 9-pin D-sub connectors, at 300 to 115,200 baud. Each channel provides a 5 V/20 mA supply for external devices, and twisted-pair cable runs of about 1,000 m are possible. Check the full order number, including any suffix, on the terminal when requesting a quote.
Technical reference
| Product name | BECKHOFF EL6022 EtherCAT 2-Channel Serial Interface Terminal |
|---|---|
| Brand | BECKHOFF |
| Model | EL6022 |
| Category | PLCs & I/O |
| Interfaces | 2 x RS422/RS485 |
| Cable length | approx. 1000 m twisted pair |
| Power supply | via the E-bus |
| Cable impedance | 120 Ω |
| Transmission rate | 300…115,200 baud; default: 9600 baud, 8 data bits, no parity and one stop bit |
| Connection technology | D-sub, 9-pin |
| Data transfer channels | 2 |
| Providing external supply | 2 x max. 5 V/20 mA, out of E-bus supply, short-circuit proof |
